Design standards: API 600, ASME B16.34, GB/T 12234, MESC SPE 77/200
Structural length: ASME B16.10, GB/T 12221
Connection standards: ASME B16.5, ASME B16.47, GB/T 9124, JB/T 79, HG/T 20592
Pressure test: API 598, GB/T 13927, GB/T 26480, JB/T 9092
Pressure and temperature rating: ASME B16.34, GB/T 12224
Main material: carbon steel, stainless steel
Nominal diameter: NPS 2 “~NPS 64” DN50~DN1600
Pressure range: CL150~CL2500 PN10~PN420
Working temperature: -196 ℃~+200 ℃
Application scope: It can be applied to flammable, explosive, and highly permeable substances, such as liquid nitrogen and LNG.
Main material: carbon steel, stainless steel
Nominal diameter: NPS 2 “~NPS 64” DN50~DN1600
Pressure range: CL150~CL2500 PN10~PN420
Working temperature: -196 ℃~+200 ℃
Application scope: It can be applied to flammable, explosive, and highly permeable substances, such as liquid nitrogen and LNG.
